Local Development Setup¶

This page takes a fresh clone of ronl-business-api to a running local stack: five Docker services, four dev servers, and a Keycloak realm with test users. It describes release v2026.09.12.

Prerequisites¶

Tool	Version	Why
Node.js	22.23.2 (`.nvmrc`); `engines` asks for `>=22`	Backend and front-end runtimes. The Azure App Services run `NODE\|22-lts`
npm	`engines` asks for `>=10`; 11.10 or newer recommended	Node 22.23.2 bundles npm 10.9.8, which silently ignores the 14-day `min-release-age` cooldown in the root `.npmrc`. `deps:check` warns and suggests `npm install -g npm@11`
Docker with Compose v2	`docker compose …`	The five local services
Git	—	Includes Git for Windows' bash, see below
bash	Any recent bash	The install, the dev start and the checks are bash scripts

A bash shell is required¶

Several root package.json scripts call bash explicitly, and the scripts they run are #!/usr/bin/env bash scripts using bash arrays:

Script	Runs
`postinstall`	`bash scripts/write-deps-marker.sh`, so `npm ci` and `npm install` themselves need bash
`deps:check`	`bash scripts/check-deps.sh`
`docker:check`	`bash scripts/check-docker.sh`
`dev`	`deps:check`, then `docker:check`, then the dev servers
`check-mirror`, `check-previews`	`bash scripts/check-mirror.sh`, `bash scripts/check-previews.sh`
`clean`	`rm -rf node_modules` (and `rm -rf dist` in each workspace), so it needs a POSIX `rm`

On macOS and Linux this needs nothing extra. On Windows, npm runs package scripts through cmd.exe, so the word bash must resolve to Git for Windows' bash.exe. It does when you work from Git Bash, or when C:\Program Files\Git\bin is on your PATH.

The Husky hooks are #!/bin/sh scripts, which Git runs with its own sh whichever terminal you use. The root .gitattributes sets * text=auto eol=lf, so the .sh files keep LF line endings on a Windows checkout and stay runnable regardless of core.autocrlf.

WSL's bash.exe (untested)

If C:\Windows\System32\bash.exe, the WSL launcher, comes before Git's bash.exe on your PATH, the scripts run inside WSL, where node, npm and docker may be different installations or missing. This combination has not been tested. If npm ci or npm run dev fails in a way that suggests the wrong tools, run where bash in cmd.exe to see which one resolves first, and work from Git Bash instead.

Clone and install¶

git clone https://github.com/sgort/ronl-business-api.git
cd ronl-business-api
nvm use            # picks up 22.23.2 from .nvmrc, if you use nvm
npm ci

Install with npm ci, not npm install. npm ci installs exactly what package-lock.json records and never rewrites it; npm install re-resolves the version ranges instead. The root npm run setup script still runs npm install && npm run docker:up, so prefer the two separate steps.

The monorepo uses npm workspaces, so one install covers all six packages: @ronl/backend, @ronl/frontend, @ronl/shared, @ronl/pa-cockpit, @ronl/pa-demo and @ronl/public-site.

Two lifecycle scripts run during the install:

The root postinstall copies package-lock.json to node_modules/.package-lock-installed.json. That snapshot is what deps:check compares against later.
The root prepare runs husky, which installs the Git hooks. @ronl/shared has its own prepare script (tsc) that builds its dist/, which the backend and the Vite front ends import. If a fresh clone reports that @ronl/shared cannot be resolved, run npm run build --workspace=@ronl/shared.

Backend environment¶

Only the backend needs a .env file you create yourself:

cp packages/backend/.env.example packages/backend/.env

The backend's config.ts loads .env.development from packages/backend/ first (the name follows NODE_ENV, which defaults to development) and then .env. dotenv never overwrites a variable that is already set, so a value in .env.development wins over the same key in .env. That file is gitignored and does not exist unless you create it.

The front ends need no setup: they run in Vite's development mode on their committed .env.development files (see Front-end configuration).

Settings to check¶

.env.example works locally as shipped, with these exceptions:

Key	What to do
`NODE_EXTRA_CA_CERTS`, `NODE_TLS_REJECT_UNAUTHORIZED=0`	Remove both lines unless you sit behind the corporate proxy they were written for. The first points at a CA file on one developer's machine (the backend logs a warning and carries on when the file is unreadable). The second switches off TLS certificate checking for every outbound HTTPS call the backend makes. Issue sgort/iou-architectuur#105 tracks removing them from `.env.example`
`ANTHROPIC_API_KEY`	Must be non-empty, or the backend refuses to start with `Configuration validation failed: ANTHROPIC_API_KEY is required`. The shipped placeholder passes the check in development; the AI assistant works only with a real key
`OPERATON_BASE_URL`	Keep `http://localhost:8081/engine-rest` with `OPERATON_USERNAME`/`OPERATON_PASSWORD` = `demo`/`demo`. `OPERATON_M2M_BASE_URL` points at the same local engine
`DATABASE_URL`	`postgresql://audit_user:audit_password@localhost:5432/audit_logs`, the database and user the Postgres container creates on first start
`LDE_MCP_ENABLED`	Set to `false` unless you create the `lde_assets` database yourself. `LDE_DATABASE_URL` points at it, but `init-databases.sql` does not create it. With the flag on, the backend still starts; the assistant's LDE tools fail when called

An unset Operaton URL reaches the shared engine

OPERATON_BASE_URL has a default, and it is not local: without the key the backend talks to https://operaton.open-regels.nl/engine-rest, and OPERATON_M2M_BASE_URL falls back to https://operaton-doc.open-regels.nl/engine-rest. Keep both keys in your .env, so local process starts and E2E runs land on your own engine.

Other defaults worth knowing:

PORT=3002. CORS_ORIGIN allows :3000, :5173 and :5175. PA-demo on :5176 does not call the backend.
EDOCS_STUB_MODE, DOCCLE_STUB_MODE and VALIDSIGN_STUB_MODE are true, so no external document, mail or signing service is called.
The backend has no LDE_API_URL in .env.example; its own calls to the Linked Data Explorer default to the ACC LDE backend.
ENABLE_SWAGGER no longer exists. The API describes itself at /v1/openapi.json.

Front-end configuration¶

Package	Committed `.env.development`
`@ronl/frontend`	`VITE_API_URL=http://localhost:3002/v1`, `VITE_KEYCLOAK_URL=http://localhost:8080`, `VITE_LDE_API_URL=http://localhost:3001/v1`, and `VITE_PA_SIGNALS_MOCK`, `VITE_PA_DOSSIERS_MOCK`, `VITE_PA_AGENDA_MOCK` all `false`
`@ronl/public-site`	`VITE_API_URL=http://localhost:3002/v1`, `VITE_STAFF_APP_URL=http://localhost:5173`, `VITE_SITE_URL=http://localhost:5175`
`@ronl/pa-demo`	The three `VITE_PA_*_MOCK` flags, all `true`

To override a value on your machine only, put it in .env.development.local next to the committed file. .env.*.local is gitignored.

VITE_LDE_API_URL points at a locally running Linked Data Explorer backend. The Procesbibliotheek section calls it directly from the browser and shows an error when nothing listens on :3001; the rest of the frontend works without it.

The Docker stack¶

npm run docker:up        # docker compose up -d

docker-compose.yml defines five services on one bridge network, ronl-network. Every image is pinned by tag and digest, and Renovate keeps the digests current (docker:pinDigests in renovate.json).

Service	Container	Image	Host port	Data
`keycloak`	`ronl-keycloak`	`quay.io/keycloak/keycloak:23.0`	8080	Its database is the `keycloak` DB in Postgres
`postgres`	`ronl-postgres`	`postgres:16-alpine`	5432	Volume `postgres-data`
`operaton-init`	`ronl-operaton-init`	`alpine:3.24.2`	—	Runs once and exits
`operaton`	`ronl-operaton`	`operaton/operaton:2.1.5`	8081 → 8080	Volume `operaton-data`
`redis`	`ronl-redis`	`redis:7-alpine`	6379	Volume `redis-data`, append-only file on

Keycloak runs start-dev --import-realm with admin account admin/admin. It waits for Postgres to report healthy, stores its data in Postgres (KC_DB=postgres), imports config/keycloak/ronl-realm.json, and loads the login themes from ./keycloak-themes. Keycloak imports the realm only when no ronl realm exists yet. Because the realm lives in the Postgres volume, an existing postgres-data volume keeps the realm it was created with.

Postgres runs as postgres/postgres. On the first start of an empty volume it runs config/postgres/init-databases.sql, which creates:

the keycloak database and user;
the audit_logs database and the user audit_user / audit_password, with full privileges on it;
in audit_logs: the audit_logs table with its indexes, and a tenants table seeded with eight tenants: utrecht, amsterdam, rotterdam, denhaag (municipalities), flevoland (province), uwv, toeslagen (national agencies) and unive (commercial).

Redis runs redis-server --appendonly yes. The backend uses it as the PA monitoring cache; /v1/health reports it but does not fail when it is down.

Keycloak, Postgres, Operaton and Redis each have a healthcheck. Keycloak and Operaton get a 60-second start period, so allow a minute on the first start:

npm run docker:logs:keycloak     # docker compose logs -f keycloak
docker compose ps                # STATUS shows (healthy) when ready

Initialising Operaton¶

The local Operaton engine starts in two steps, both in docker-compose.yml.

operaton-init mounts the operaton-data volume, runs chown -R 1000:1000 /data, and exits. The Operaton image runs as the non-root user with uid 1000, but Docker creates a new named volume owned by root. Without this step the engine crashes on a fresh volume with java.nio.file.AccessDeniedException on its .mv.db file. The step is idempotent, so it runs harmlessly on every docker compose up.
operaton starts only after that container has exited successfully (depends_on: operaton-init: condition: service_completed_successfully). It uses an H2 file database, jdbc:h2:file:/operaton/h2-data/operaton-local, on the operaton-data volume, so no external database is involved. It runs with TZ=Europe/Amsterdam and -XX:MaxRAMPercentage=70.0, and listens on host port 8081. Its healthcheck is a TCP probe on the container's port 8080.

The engine REST API is at http://localhost:8081/engine-rest, and the Operaton web apps are served on http://localhost:8081. The backend's .env.example uses demo/demo for both.

The engine starts empty¶

Nothing in this repository deploys BPMN or DMN. A fresh engine has no process definitions, so any process start fails until you deploy some.

The reference bundle lives in the sibling Linked Data Explorer repository, under linked-data-explorer/e2e-fixtures/, and is deployed through the LDE's BPMN Modeler. Run the LDE locally first. Then:

What	How to deploy it
Processes, in `e2e-fixtures/<tenant>/`	Import each process and set the Organization field to the tenant folder name (`flevoland` or `toeslagen`). That value becomes the Operaton `tenant-id`
Decisions, listed under `sharedDecisions.files` in `e2e-fixtures/manifest.json`	Import each one with the Organization field empty. The processes resolve their decisions untenanted (`decisionRefTenantId="${null}"`), so a decision deployed under a tenant is not found
`zorgtoeslag_resultaat`	Not in the fixture bundle. `manifest.json` lists it under `sharedDecisions.external`: it ships with the zorgtoeslag rules set

The frontend E2E suite refuses to run until this is done: its global-setup.ts calls verifyRequiredProcesses() and verifyRequiredDecisions() against the engine and names what is missing. See What each suite needs running.

Deployments persist in the operaton-data volume across restarts. They are lost on npm run docker:down:volumes, which also wipes the Keycloak realm, the audit database and Redis.

Starting the development servers¶

npm run dev

npm run dev runs three steps in order, and stops at the first one that fails:

deps:check (scripts/check-deps.sh) compares package-lock.json with the snapshot the last install left in node_modules. It parses both files and ignores this repository's own package version numbers, so a release bump does not trip it and line endings do not matter. When a third-party dependency has changed, it stops and tells you to run npm ci, with a reminder that npm ci deletes node_modules first and so takes down any dev server running from it. It never installs anything itself. It also warns, without failing, when npm is older than 11.10.
docker:check (scripts/check-docker.sh) checks that Docker is running and that four containers are running and healthy: ronl-keycloak, ronl-postgres, ronl-redis and ronl-operaton. When one is missing or not yet healthy it stops and tells you to run npm run docker:up.
concurrently starts four dev servers:

Server	Command	URL
Backend	`tsx watch src/index.ts`, after its `predev` script has run `build:openapi`	`http://localhost:3002`
Frontend (MijnOmgeving)	`vite`	`http://localhost:5173`
Public site	`vite`	`http://localhost:5175`
PA-demo	`vite`	`http://localhost:5176`

The Vite servers bind to 0.0.0.0. The backend binds to HOST from .env (0.0.0.0 in .env.example) and logs API available at: …/v1 when it is up. Before it listens it initialises its database tables and, with MCP_ENABLED=true, connects the AI-assistant sources; a source that fails to connect is logged and skipped.

Open http://localhost:5173. The frontend redirects you to Keycloak to log in.

Why the demo starts too

The PA-demo renders from the shared @ronl/pa-cockpit package rather than its own copy, so a cockpit change affects both it and the caseworker frontend. Starting one without the other makes it easy to verify the frontend and miss the demo.

To run a single server, use its root script: npm run dev:backend, dev:frontend, dev:public-site or dev:pa-demo. These skip both checks.

Test users¶

config/keycloak/ronl-realm.json defines 22 users, all with password test123 and assurance level hoog. The municipality attribute is the user's tenant.

Tenant	Username	Realm roles
utrecht	`test-citizen-utrecht`	citizen
utrecht	`test-caseworker-utrecht`	caseworker
amsterdam	`test-citizen-amsterdam`	citizen
amsterdam	`test-caseworker-amsterdam`	caseworker
rotterdam	`test-citizen-rotterdam`	citizen
rotterdam	`test-caseworker-rotterdam`	caseworker
denhaag	`test-citizen-denhaag`	citizen
denhaag	`test-caseworker-denhaag`	caseworker
denhaag	`test-hr-denhaag`	caseworker, hr-medewerker
denhaag	`test-onboarded-denhaag`	caseworker
flevoland	`test-citizen-flevoland`	citizen
flevoland	`test-caseworker-flevoland`	caseworker
flevoland	`test-hr-flevoland`	caseworker, hr-medewerker, board-secretary, board-director, hrm-unit, procurement-unit, planning-control-officer, financial-controller, hr-business-partner, personnel-controller
flevoland	`test-mngr-flevoland`	caseworker, manager
flevoland	`test-infra-flevoland`	caseworker, infra-projectteam, infra-medewerker, and the RIP project roles (`rip-*`)
flevoland	`test-pa-flevoland`	public-affairs, pa-author, pa-editor, pa-admin
flevoland	`test-woo-flevoland`	woo-coordinatie
uwv	`test-citizen-uwv`	citizen
uwv	`test-caseworker-uwv`	caseworker
toeslagen	`test-citizen-toeslagen`	citizen
toeslagen	`test-caseworker-toeslagen`	caseworker
unive	`test-citizen-unive`	citizen

The Keycloak admin console is at http://localhost:8080 with admin/admin.

Verifying the setup¶

curl -s http://localhost:3002/v1/health

A healthy local stack answers 200. This response was captured from the local stack on 26 September 2026, at v2026.09.12; timestamp, uptime, duration and the latencies differ on every call:

{
  "success": true,
  "data": {
    "name": "RONL Business API",
    "version": "2026.09.12",
    "build": null,
    "status": "healthy",
    "timestamp": "2026-09-26T20:44:28.620Z",
    "uptime": 119.675175,
    "environment": "development",
    "duration": 30,
    "dependencies": {
      "keycloak": {
        "status": "up",
        "latency": 18
      },
      "operaton": {
        "status": "up",
        "latency": 12
      },
      "cache": {
        "status": "up"
      }
    }
  }
}

status is healthy only when Keycloak and Operaton are both up; then the endpoint answers 200. Otherwise it is degraded, success is false, and the endpoint answers 503. A down dependency carries an error field instead of latency.
cache is Redis. It is reported but never makes the check fail.
build is null in a working tree; the deploy workflow fills it in.
environment comes from DEPLOYMENT_ENV, falling back to NODE_ENV.

/v1/health/live and /v1/health/ready are the liveness and readiness probes. The OpenAPI description is at http://localhost:3002/v1/openapi.json; see the API Specification.

Calling the API with a token¶

The realm's ronl-business-api client is a public client with direct access grants enabled, so a password grant needs only the client ID. There is no client secret.

TOKEN=$(curl -s -X POST http://localhost:8080/realms/ronl/protocol/openid-connect/token \
  -d client_id=ronl-business-api \
  -d grant_type=password \
  -d username=test-citizen-utrecht \
  -d password=test123 \
  | node -pe "JSON.parse(require('fs').readFileSync(0, 'utf8')).access_token")

node -pe parses the response so you do not need jq. The client's protocol mappers put the ronl-business-api audience, the realm roles and the municipality, organisation_type and assurance_level attributes in the token.

Read the start form of a deployed process:

curl -s http://localhost:3002/v1/process/AwbZorgtoeslagProcess/start-form \
  -H "Authorization: Bearer $TOKEN"

Start it with the form's fields as variables, from a JSON file of your own:

curl -s -X POST http://localhost:3002/v1/process/AwbZorgtoeslagProcess/start \
  -H "Authorization: Bearer $TOKEN" \
  -H "Content-Type: application/json" \
  -d @zorgtoeslag-start.json      # { "variables": { … } }

AwbZorgtoeslagProcess is one of the fixture processes, deployed under the toeslagen tenant. Because test-citizen-utrecht is a citizen, the backend starts the case under the deployment's tenant: municipality is toeslagen, originTenantId is utrecht, and the business key starts with toeslagen-. Staff get 403 TENANT_MISMATCH when they start another tenant's process; see Tenancy. On success the endpoint answers 201 with processInstanceId, businessKey, status and startTime.

Before the fixtures are deployed, both calls fail, and the start's error.details carries Operaton's own message. This start call has not been run end to end for this page.

Database access¶

docker exec -it ronl-postgres psql -U postgres -d audit_logs

SELECT * FROM audit_logs ORDER BY timestamp DESC LIMIT 10;
SELECT tenant_id, name, organisation_type FROM tenants;
\q

Connect with -U audit_user to see what the backend sees. The Keycloak data is in the keycloak database of the same container.

Redis:

docker exec -it ronl-redis redis-cli ping      # PONG

Service URLs¶

Service	URL	Credentials
Frontend (MijnOmgeving)	`http://localhost:5173`	Test users above
Public site	`http://localhost:5175`	—
PA-demo	`http://localhost:5176`	— (mock data only)
Backend API	`http://localhost:3002/v1`	Bearer token
Health	`http://localhost:3002/v1/health`	—
OpenAPI	`http://localhost:3002/v1/openapi.json`	—
Keycloak admin console	`http://localhost:8080`	`admin` / `admin`
Operaton web apps	`http://localhost:8081`	`demo` / `demo`
Operaton REST API	`http://localhost:8081/engine-rest`	`demo` / `demo`
PostgreSQL	`localhost:5432`	`postgres` / `postgres`; `audit_user` / `audit_password` for `audit_logs`
Redis	`localhost:6379`	—
LDE backend (optional, sibling repo)	`http://localhost:3001/v1`	—

Stopping and resetting¶

# Ctrl+C in the npm run dev terminal stops the four dev servers
npm run docker:down           # stop the containers, keep the volumes
npm run docker:down:volumes   # stop the containers and delete all four volumes

docker:down:volumes removes keycloak-data, postgres-data, operaton-data and redis-data. On the next npm run docker:up, Postgres runs init-databases.sql again, Keycloak re-imports the realm, and Operaton starts empty, so you deploy the fixtures again.

Git hooks¶

Husky installs two hooks during npm ci:

Hook	Runs
`pre-commit`	`npx lint-staged`: ESLint `--fix` in the owning workspace and `prettier --write` on the staged files
`pre-push`	`deps:check`, then `npm run build --workspace=@ronl/shared`, `type-check`, `lint` and `check-format`

deps:check comes first in pre-push so that a push from a stale install stops with npm ci named as the fix, instead of the later checks failing on the wrong tool versions. On 14 September 2026 a clone still on Prettier 3.8.1 after the lockfile moved to 3.9.6 failed check-format on seven correctly formatted files with nothing saying why.

For running the test suites, see Testing.

Common issues¶

bash is not recognized, or npm ci fails in postinstall: npm cannot find bash. On Windows, work from Git Bash or put C:\Program Files\Git\bin on your PATH. See A bash shell is required.
deps:check says the install is stale: Stop the dev servers and run npm ci.
docker:check lists a container as not running or not yet healthy: Run npm run docker:up and wait for docker compose ps to show all four as healthy. Keycloak and Operaton take up to a minute on first start.
Operaton exits with AccessDeniedException on its .mv.db file: The volume is still owned by root. Check that operaton-init ran: docker compose logs operaton-init, then docker compose up -d again.
The backend exits with Configuration validation failed: ANTHROPIC_API_KEY is empty or missing in packages/backend/.env.
A process start fails with no matching process definition: The local engine is empty. See The engine starts empty.
The realm is missing, or the token lacks the audience or roles: The realm lives in Postgres, and Keycloak skips the import when a ronl realm already exists. A postgres-data volume from an older realm file keeps the older client configuration. The current ronl-realm.json already carries the audience and realm-role mappers on the ronl-business-api client, so resetting with npm run docker:down:volumes && npm run docker:up picks them up. That also clears the audit database and the Operaton deployments. scripts/keycloak-add-token-claim-mappers.sh adds only the email, given_name and family_name mappers that ValidSign signing needs, to an existing client, without a re-import.
CORS error in the browser: Check that CORS_ORIGIN in packages/backend/.env lists the origin exactly, including the port.
Procesbibliotheek shows an error: The LDE backend is not running on :3001. Start it from the LDE repository, or ignore the section.

For more, see Troubleshooting.
